Setting data which can be backed up
The following is the detailed list of the setting data.
Type Name Description
Setting data of the
line
System setting System setting includes the following configuration.
• The data of System Settings dialog box:
Refer to Section 4 Setting the Controller on page 4 - 1.
• The layout information of the layout 0 to 8:
Refer to 8-3 Arranging Windows [Layout Functions] on page
8 - 12.
*1
• The User Data:
Refer to A-12 Sharing Data Within the Controller [User Data
Tool] on page A - 37.
System variables They are enabled within a defined line settings. Although they can
be set and referenced across scenes and scene groups, they can-
not be set and referenced in different lines with multiple line ran-
dom modes. For details, refer to 5-5-1 Edit Flow Screen on page
5 - 14 and 5-5-4 Using Variables on page 5 - 43.
Scene group saving
destination
Setting contents of the Scene grope saving destination are the
setting object.
Refer to 7-5 Saving Scene Groups in External Storage [Scene
Group Saving Destination Settings] on page 7 - 11.
Scene group
Scene grope saved to Sensor Controller or external memory(
*2
)
are the setting object.
All of the following settings include to Scene grope
• Flow Settings of all scenes.
• Macro code of Scene Control Macro for all Scene.
Refer to Components of the Setting Screen of the
Communication Command Macro Tool and How to Configure
Settings in the Vision System FH Series Macro Customize
Functions Programming Manual (Cat. No. Z367).
• Image Window Settings of all scenes.
Refer to 3-2-7 Changing the Image Mode and Other Display
Contents on page 3 - 21.
Communication
command macro
The target data is the Communication Command Macro data.
Refer to Components of the Setting Screen of the Communication
Command Macro Tool and How to Configure Settings in the
Vision System FH Series Macro Customize Functions
Programming Manual (Cat. No. Z367).
Custom dialog The target data is all setting of the Custom dialog.
Refer to 8-4 Editing contents are not reflected when you confirm
the Sensor Controller after edit a layout by remote control [Cus-
tom Dialog Tool] on page 8 - 64.
Security setting Security settings include the following configuration.
• Account list
• Layout restrictions
• Operating restrictions
Refer to 10-3-4 Saving/Loading/Deleting the Security Settings
on page 10 - 36.
Image in image file
display window
Images displayed in image file display pane.
For details, refer to 8-3-12 Image File Display Pane on page
8 - 34.
9 Saving/Loading Data
9 - 16
FH/FHV Series Vision System User’s Manual (Z365-E1)
