About Max. Number of Loading Im-
ages during Multi-input
The function that enables continuous high speed image input is called the multi-input function.
The maximum number of images that can be loaded based on each specification is shown below.
A-8-1
FH series
Model of Sensor
Controller
CCD camera (0.3 mega
pixels)
CCD camera (2 mega
pixels)
CCD camera (5 mega
pixels)
FH-1 £££
FH-1£££-££
FH-3 £££
FH-3 £££-££
FH-2 £££
FH-2 £££-££
FH-5 £££
FH-5 £££-££
FH-L £££
FH-L £££-££
256 64 25
Model of Sensor
Controller
CMOS
camera
(0.3
mega
pixels)
CMOS
camera
(0.4
mega
pixels)
CMOS
camera
(2 mega
pixels)
CMOS
camera
(4 mega
pixels)
CMOS
camera
(5 mega
pixels)
CMOS
camera
(12 mega
pixels)
CMOS
camera
(20.4
mega
pixels)
FH-1 £££
FH-1£££-££
FH-3 £££
FH-3 £££-££
FH-2 £££
FH-2 £££-££
FH-5 £££
FH-5 £££-££
FH-L £££
FH-L £££-££
256 256 51 32 25 10 6
Precautions for Correct Use
• The multi-input function cannot be used when the built-in lighting of an Intelligent Compact
Digital Camera, FZ-SQ££££, is used.
• The maximum number of images loaded does not change even if partial reading of camera
images is selected.
When using two camera cables for connection, the maximum number of loaded images dur-
ing multi-input is twice the number given in the table.
A-8-2
FHV series
Appendices
A - 27
FH/FHV Series Vision System User’s Manual (Z365-E1)
A-8 About Max. Number of Loading Images during Multi-
input
A
A-8-1 FH series
