Main
menu
Command Description Reference
System restart Restarts the Controller. 3-6-3 Restarting the Controller
[System Restart] on page 3 - 33
Section 9 Saving/Loading Data on
page 9 - 1
Transfer data Transfers (copies) the settings for
line 0 to line 1, and then changes to
the Non-stop Adjustment Mode.
Non-stop Adjustment Mode on
page 4 - 23
Non-stop data transfer Transfers (copies) the settings for
line 1 to line 0 in Non-stop Adjust-
ment Mode without affecting meas-
urements.
Operation log Saves the operation log of the Con-
troller to a special file.
10-4-1 Using the Operation Log on
page 10 - 42
System information Displays the Controller’s model and
software version.
3-3 Checking System Information
[System Information] on page
3 - 24
Tool TDM editor Edits the processing flow using var-
iables.
5-5 Using Variables to Edit the Flow
[TDM Editor] on page 5 - 14
System settings Sets settings that are related to the
system environment of the Control-
ler. Includes settings such as the
startup settings, Camera settings,
and communications settings.
Section 4 Setting the Controller on
page 4 - 1
Security settings Used to set accounts and limit ac-
cess to the Controller.
10-3 Limiting User Operations [Se-
curity Settings] on page 10 - 29
Scene Group Saving
Destination Settings
Changes the location for saving
scene group data to the sensor
controller’s memory or external
storage.
7-5 Saving Scene Groups in Exter-
nal Storage [Scene Group Saving
Destination Settings] on page 7 - 11
NG analyzer Used to analyze NG causes based
on image data.
6-4 Analyzing Inspection and
Measurement Results [NG Ana-
lyzer] on page 6 - 26
User data tool Sets the initial value for user data
that can be shared across scenes
and across scene groups.
A-12 Sharing Data Within the Con-
troller [User Data Tool] on page
A - 37
Settings download and
upload
Used to download and upload a list
of set values for scene data as a
CSV file.
9-10 Outputting a list of Scene Data
Setting Values [Setting Values
Download/Upload Tools] on page
9 - 49
Layout download and
upload
Saves the layout settings of the
Main Window in a file and loads the
settings.
9-11 Saving/Loading Layout Set-
tings [Layout Upload, Download
Tool] on page 9 - 53
Image file save Saves logged images and image
files that are saved in the Control-
ler.
9-9 Saving Image Files to a RAM-
Disk or an External Storage Device
[Image File Save] on page 9 - 46
Registered image
Manager
Used to register the most recent in-
put image, a logged image that is
saved in the Controller or an image
file and load it as a measurement
image.
6-6 Managing Images used for
Model Registration and Reference
[Registered Image Manager] on
page 6 - 38
Appendices
A - 4
FH/FHV Series Vision System User’s Manual (Z365-E1)
