Omron NJ Series Network Connection Guide

7. Connection Procedure
7. Connection Procedure
This section describes the procedure for connecting the Controller on the EtherNet/IP network
using the "procedure for using configuration files".
This document explains the setting procedure of the Controller and the Displacement Sensor
with their default settings. For information on how to initialize each device, refer to Section 8
Initialization Method.
Personal computer
Controller
17
Destination
device
7.1. Overview of Setting Tag Data Links
The following figure shows the relationship between the processes to operate the tag data
links using the "procedure for using configuration files".
Transferring
project data
Sysmac Studio
Importing
project file
Transferring tag
data link parameters
Opening network
configuration file
Network Configurator
Sysmac Studio project file
Network Con
figurator version 3
network configuration file
Configuration files
Precautions
for Correct Use
Prepare the latest "Sysmac Studio project file" and "Network Configurator v3 network
configuration file" from OMRON in advance.
(To obtain the file, contact your OMRON representative.)
