Omron NJ Series Network Connection Guide

9. Appendix 1 Detailed Settings of the Tag Data Links
52
9.3. Associating the Tag Data Links
Tag data link parameters are required to perform tag data links with a destination device.
Follow the procedures below to associate the tag data links.
(1)Define the global variables to publish on the network by using the Sysmac Studio.
Store the created global variables in a CSV file to use in the Network Configurator.
(2)Read the CSV file (tag list) created in step 1 to the Network Configurator.
(3)Install the EDS file for the destination device in the Network Configurator.
(4)Make a single tag set that includes the tag lists.
(5)Link the tag set with the destination device information and create tag data link
parameters.
The numbers shown in the tables below correspond to the steps above.
■Output area (Controller → Displacement Sensor)
Controller setting
(Set with Sysmac Studio.)
Data link table setting
(Set with Network Configurator.)
Destination device
information (EDS file
setting contents)
(1)
Tag set: EIPOutput 24 bytes
(5)
←
(3)
Output_100-[24
Byte]
Global variable (Data type) (4) Tag list
EIPOutput S_EIPOutput
→
(2)
EIPOutput
(24
bytes)
*For details,
refer to Section
9.2.
■Input area (Controller ← Displacement Sensor)
Controller setting
(Set with Sysmac Studio.)
Data link table setting
(Set with Network Configurator.)
Destination device
information (EDS file
setting contents)
(1)
Tag set: EIPInput 56 bytes
(5)
←
(3)
Input_101-[56By
te]
Global variable (Data type) (4) Tag list
EIPInput S_EIPInput
→
(2)
EIPInput
(56
bytes)
*For details,
refer to Section
9.2.
