Omron NJ Series Network Connection Guide

10. Appendix 2 Setting the Tag Data Links Using the Software
10.3. Setting Up the Controller Using the Software
Set up the Controller using the software.
10.3.1. Starting the Sysmac Studio and Setting the Parameters for the
Controller
Start the Sysmac Studio and set the parameters for the Controller.
1
Connect the LAN cable and the
USB cable to the Controller, and
turn ON the power supply to the
Controller.
*For details, refer to step 1 of
7.4.1. Starting the Sysmac
Studio and Importing the
Project File.
2
Start the Sysmac Studio.
Click the New Project Button.
*If a confirmation dialog for an
access right is displayed at
start, select to start.
56
