3 Specifications
3 - 28
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
3-3 Linear Motor Specifications
Two types of Linear Motors are available: Iron-core and Ironless Linear Motors.
These Linear Motors consist of one Motor Coil Unit and two or more Magnet Track.
The Motor Coil Unit has built-in temperature sensors.
Choose an appropriate Linear Motor model based on the load and the operating characteristics.
*1 The amplitude may be increased by machine resonance. As a guideline, do not exceed 80% of the specified
value.
*2 Disconnect all connections to the Linear Motor before attempting a megameter test (insulation resistance
measurement) on a Linear Motor. Failure to follow this guideline may result in damaging the Linear Motor. In
addition, never perform dielectric strength tests on the Linear Motor. Failure to follow this guideline may result
in damaging the internal elements.
3-3-1 General Specifications of Iron-core Linear Motors
Item Description
Operating ambient temperature humidity 0 to 40ºC, 20% to 80% (with no condensation)
Storage ambient temperature and humidity –20ºC to 65ºC, 85% max. (with no condensation)
Operating and storage atmosphere No corrosive gases
Vibration resistance
*1
Acceleration of 49 m/s
2
max. in X, Y, and Z directions
Impact resistance
Acceleration of 98 m/s
2
max. 3 times each in X, Y, and Z
directions
Insulation resistance
*2
Between power terminal and FG terminal: 10 MΩ min. (at
500 VDC)
Dielectric strength
Between power terminal and FG terminal: 2,750 VDC for 1 s
Between power terminal and sensor: 2,750 VDC for 1 s
Protective structure IP00
Maximum coil temperature (Motor Coil Unit) 130°C
Maximum magnet temperature (Magnet Track) 70°C
Insulation class Class B
Cooling method Self-cooling
