4 System Design
4 - 4
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
Before operating the Linear Motor, it is necessary to assemble parts such as the linear guides and the
external encoder into the Linear Slider, in addition to the Motor Coil Unit and the Magnet Track.
An example of the Linear Slider is shown below.
When designing a Linear Slider, prepare proper parts for the system and implement sufficient
measures to ensure safety operation.
4-1-2 Iron-core Linear Motor Installation Conditions
Stopper
Linear guide
Connector box
External
encoder
Motor Coil Unit
Magnet Track
To Next Page
