Omron R88D-KN01L-ECT-L User Manual

4 - 17
4 System Design
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
4-2 Wiring
4
4-2-1 Peripheral Equipment Connection Examples
R88D-KN30F-ECT-L
OFF ON
X
1MC
24 VDC
B1
B3
B2
(*4)
(*3)
CN1
CN1
TB1
TB2
TB1
X
X
1MC
1MC
W
V
U
CN4
L3
ALMCOM
/ALM3
4
X
24 VDC
1
2
BKIR
BKIRCOM
XB
24 VDC
123
456
E
NF
24 V
0 V
L1
L2
RT
NFB
S
PL
ECAT
IN
OUT
LM
*1. A recommended product is listed in 4-3,
Wiring Confirming to EMC Directives.
*2.
Do not use shielded cables for power cables.
*3. Recommended relay: MY relay by OMRON
(24 VDC 2A)
Select one that matches the ratings of the
brake etc. to be used.
*4. Model with a built-in Regeneration Resistor
(KN30F-ECT-L) has B2 and B3 shorted.
When the amount of regeneration is large,
remove the connection between B2 and B3
and connect the Regeneration Resistor
between B1 and B2.
G5-series AC Servo Drive
3-phase 380 to 480 VAC, 50/60 Hz
Main circuit
power supply
Surge suppressor (*1)
User-side
control
device
Noise filter (*1)
Ground to
10 Ω or less
Servo error display
External encoder
cables
Power cables (*2)
Regeneration
resistor
Reactor
Motor
coil unit
External
encoder
Ground to
10 Ω or less
General-purpose
inputs 1 to 8
External sensor, etc.
Main circuit contactor (*1)
