2 Models and External Dimensions
2 - 6
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
z Motor Coil Unit
z Magnet Track
Ironless family
R88L-EC-GW-0303-ANPS
03 : 30 mm
05 : 50 mm
07 : 70 mm
GW: Ironless family
Motor Coil Unit
03 :
06 :
09 :
A : Ver.A
NP: Not provided
S: Standard type
Coil Model
Version
Connector
Type
G5-series Linear Motor
Component Type
Effective Magnet Width
3-coil
6-coil
9-coil
R88L-EC-GM-03090-
A
03 : 30 mm
05 : 50 mm
07 : 70 mm
GM: Ironless family
Magnet Track
090 : 90 mm
114 : 114 mm
120 : 120 mm
126 : 126 mm
168 : 168 mm
171 : 171 mm
210 : 210 mm
390 : 390 mm
456 : 456 mm
546 : 546 mm
A : Ver.A
Magnet Track Unit Length
Version
G5-series Linear Motor
Component Type
Effective Magnet Width
