Configuration of Instrumentation System Section 1-2
Note When using function component version 3.6 for LCB01, LCB03, or LCB05,
use the CX-One Auto Update function to update the CX-Process Tool Soft-
ware to version 5.23 or higher.
1-2 Configuration of Instrumentation System
1-2-1 Mounting Location
Loop Control Boards
CS1W-LCB01 Loop
Control Board
The CS1W-LCB01 Loop Control Board is a non-duplex Inner Board for the
CS-series PLCs. It can be mounted in a CS1-H CPU Unit. It is not supported
by and cannot be mounted in a CS1 CPU Unit.
Switch control action direction func-
tion
(Can switch the control action direc-
tion when operating the Basic PID
block (Block Model 011) or Advanced
PID (Block Model 012) in Auto mode.)
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
Reference sequence table function
(Can reference another table's condi-
tion judgment in the Sequence Table
block (Block Model 302).)
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
Added timer function
(Can specify a TIM (timer) command
in the Step Ladder block (Block Model
301).)
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
Pulse output function
(Can generate a pulse output (ON for
1 refresh cycle) in the user link table.)
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
Expanded user link table EM specifi-
cation
(EM banks other than EM bank 0
(EM0) can be specified as data areas
in the user link table.)
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported
banks EM1
to EMC can
be speci-
fied.
Supported
banks EM1
to EMC can
be speci-
fied.
Supported
banks EM1
to EMC can
be speci-
fied.
Number of constants that can be set
for the Constant ITEM Setting (Block
Model 171) increased from 8 maxi-
mum to 16 maximum.
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
Including block diagram information,
tags, comments, and annotation data
in easy backup data along with func-
tion block data
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
Changing the data that is backed up
for easy backup function from RAM
data to flash memory data
Not sup-
ported
Not sup-
ported
Not sup-
ported
Supported Supported Supported
Item Ver. 1.0 Ver. 1.5 Ver. 2.0 Ver. 3.0 Ver. 3.5 Ver. 3.6
Mount in the Inner Board slot.
CPU Rack
CS1-H CPU Unit
To Next Page
