Onkyo T-4070 User Manual

En-11
Connecting Antennas—Continued
1
Screw the supplied DAB antenna’s plug
onto the DAB ANTENNA jack.
Once your tuner is ready for use, you’ll need to
tune into a DAB station and adjust the position of
the DAB antenna to achieve the best possible
reception.
2
Use thumbtacks or something similar to fix
the DAB antenna into position.
Connecting the DAB Antenna

Onkyo T-4070 Specifications

General

Power consumption (typical)	28 W
Product color	Silver
FM preset stations	40
Supported radio bands	AM, DAB+, FM
Built-in storage media	No
Audio formats supported	AAC, FLAC, MP3, OGG, WAV, WMA
Internet radio services supported	Last.fm, Spotify, vTuner
Network streaming services supported	-
Number of drivers	0
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	306.7 mm
Width	435 mm
Height	100 mm
Weight	5800 g
