Onkyo T-4070 - Rear Panel; Display

En-8
Getting to Know the Tuner—Continued
For detailed information, see the pages in parentheses.
a AUDIO OUTPUT jacks (12, 13)
b FM ANTENNA jack and AM ANTENNA
terminal and DAB ANTENNA jack (10, 11)
c  REMOTE CONTROL jack (12, 14)
d DIGITAL OUT COAXIAL and OPTICAL and
AES/EBU jacks (12, 13)
e ETHERNET port (29)
f AC INLET terminal (15)
See “Connecting Antennas”, “Connecting Your
Components” for connection ( pages 10 to 15).
For detailed information, see the pages in parentheses.
a M.Opt indicator
b ,  indicators
c Message area
d Tuning indicators
• RDS indicator (21)
• AUTO indicator (16)
• TUNED indicator (16)
• FM STEREO indicator (16)
e NET indicator (26)
f USB indicator (23)
g SLEEP indicator (24)
Rear Panel
1
2
5
4
3
6
Display
21
3
4
5
6
7
