209
Appendix
Audio Inputs North American models European models Australian and Asian models
Analog 7 (Including 1×PHONO)
Digital
2 (C OA X IA L×1, O P TI CA L×1)
• Supported sampling rates for PCM signals (stereo, mono) from a digital input are 32 kHz, 44.1 kHz, 48 kHz,
88.2 kHz, 96 kHz/16bit, 20bit, and 24bit.
Audio Outputs North American models European models Australian and Asian models
Analog
FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R, SURROUND BACK L/R, HEIGHT 2 L/R or ZONE 3
L/R, 2 SUBWOOFER
ZONE B LINE OUT or ZONE 2 PRE/LINE OUT
HEIGHT 2 PREOUT or ZONE 3 PRE/LINE OUT
Speaker Outputs
FRONT L/R, CENTER,
SURROUND L/R, HEIGHT 1 L/R
or Bi-AMP, SURROUND BACK L/R
or HEIGHT 2 L/R or ZONE 3 L/R,
ZONE 2 L/R (banana plug ready)
FRONT L/R, CENTER, SURROUND L/R, HEIGHT 1 L/R or ZONE 2 L/R or
Bi-AMP, HEIGHT 2 L/R or SURROUND BACK L/R or ZONE 3 L/R
Phones 1 (ø 6.3 mm, 1/4")
Others North American models European models Australian and Asian models
Setup Mic 1 (Front)
RS-232 1
12V TRIGGER OUT 1 (100mA)
IR 1 (IN)
Specications and features are subject to change without notice.
