Onkyo TX-RZ50 User Manual

Speaker Connections
7.1.2ch
7.1ch
5.1. 2ch
5.1.4ch
7.1.4ch
5.1c h
38
Speaker Connections
Speaker Connections
(Before starting the procedure)
Speakers you can use with this unit and cable
connections 39
4-16Ω
A
B
C
Connect the Subwoofer 40
5.1 Channel System 41, 42, 43, 44
7.1 Channel System 45, 46, 47, 48
5.1.2 Channel System 49, 50, 51, 52, 53
7.1.2 Channel System 54, 55
5.1.4 Channel System 56, 57
7.1.4 Channel System 58, 59
Connecting a Power Amplier 60
Speaker Connections

Onkyo TX-RZ50 Specifications

General

Impedance	16 Ω
Receiver type	Surround
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
4Ω speaker support	Yes
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (20-20KHz@8 Ohm)	250 W
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	850 W
HDMI in	6
USB ports quantity	1
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Wi-Fi	No
AirPlay	-
Display	LCD
Product color	Black
Audio decoders	DTS:X, Dolby Atmos
THX-certified	THX
Cables included	AC
