4.Advanced User Guidebook
Note: When the autoscale is turned on and running, the Autoset button is
invalid.
Description for icon:
Cancel Autoset: Go back to display the upper menu and waveform information.
Note: The Autoset function requires that the frequency of signal should be no
lower than 20Hz, and the amplitude should be no less than 5mv. Otherwise,
the Autoset function may be invalid.
Print the Screen Image
To print an image of what appears on the oscilloscope screen, do as the
follows:
(1) Connect the printer to the USB Device port on the side panel of the
oscilloscope.
Note: The USB Device port supports PictBridge compatible printers.
(2) Click to call up the menu panel. Click the Utility softkey on panel,
select Function in the bottom menu, select Output in the left menu.
(3) In the bottom menu, select Device as PICT. (When PC is selected, you
can get an image by Oscilloscope software.)
(4) In the bottom menu, select Print Set. In the right menu, set the print
parameters. The On selection of Ink Saver will print out a copy with a
white background.
(5) Once you have connected a printer to your oscilloscope and set up print
parameters, click Play in the bottom menu to print current screen images.
