Owon TAO3000 Dual-Channel Series User Manual

4.Advanced User Guidebook
48
you can set anyone of them, the other will be changed synchronously.
Decoded information interpretation:
Information
Abbreviation
Background
Identifier
I, ID, or do not display
Green
Overload Frame
OF
Green
Error Frame
EF
Green
Data Length code
L, DLC, or do not display
Blue
Data
D, Data, or do not display
Black
Cyclic Redundancy Check
C, CRC, or do not display
Valid: Purple
Error: Red
Note:
 Use the upper knob to adjust the thresholds of bus trigger and bus
decoding.
 When the ACK (ACKnowledge Character) of Data Frame or Remote
Frame is not met, two red error marks will be displayed in the
corresponding position in the waveform.
 Error Frame, Remote Frame, and Overload Frame will be identified in the
"Data" column in the event table (Data Frame will not be identified).
CAN Decoding menu list:
Menu
Setting
Instruction
Bus
Type
CAN
Set bus type of decoding as CAN.
Display
Format
Binary
Decimal
Hex
ASCII
Set the display format of the bus.
EventTable
ON
OFF
Select "ON" to display the event table.
Save
EventTable
If a USB storage device is currently connected to the
instrument, save the event table data in a .csv
(spreadsheet) formatted file on the external USB
storage device.
ASCII Table
ON
OFF
Select "ON" to display the ASCII table.
Implement Sampling Setup
Click to call up the menu panel. Click the Acquire softkey on panel, Acqu
