Owon TAO3000 Dual-Channel Series User Manual

4.Advanced User Guidebook
76
Screen menu button twice to set the cursor range.
Statistics
Select Statistics, you can choose On or Off to enable or disable statistics on
the measurement value.
Statistics reset: Restart statistics on statistics.
Measure with Cursors
Click to call up the menu panel. Click the Cursor softkey on panel to
switch to the ON state and display the cursor menu. Click it again to turn
cursors off.
The Cursor Measurement for normal mode:
The description of the cursor menu is shown as the following table:
Function
Menu
Setting
Description
Type
Voltage
Time
Time&Voltage
AutoCursr
Display the voltage measurement cursor and
menu.
Display the time measurement cursor and
menu.
Display the time and voltage measurement
cursor and menu.
The horizontal cursors are set as the
intersections of the vertical cursors and the
waveform
Line
Type
(Time&Volt
age type)
Time
Voltage
Makes the vertical cursors active.
Makes the horizontal cursors active.
Window
(Wave
zoom
mode)
Main
Extension
Measure in the main window.
Measure in the extension window.
Source
CH1 or CH2
Display the channel to which the cursor
measurement will be applied.
Perform the following operation steps for the time and voltage cursor
measurement of the channel CH1:
1. Click to call up the menu panel. Click the Cursor softkey on panel
to switch to the ON state and display the cursor menu.
2. Select Source in the bottom menu, select CH1 in the right menu.
3. Select the first menu item in the bottom menu, the Type menu will
display at the right of the screen. In the right menu, select
Time&Voltage for Type, two blue dotted lines displayed along the
