Owon TAO3000 Dual-Channel Series User Manual

10.Technical Specifications
129
Performance Characteristics
Instruction
Automatic
Period, Frequency, Mean, PK-PK, RMS,
Max, Min, Top, Base, Amplitude, Overshoot,
Preshoot, Rise Time, Fall Time, +Pulse
Width, -Pulse Width, +Duty Cycle, -Duty
Cycle, Delay A→B , Delay A→B , Cycle
RMS, Cursor RMS, Screen Duty, FRR, FRF,
FFR, FFF, LRR, LRF, LFR, LFF, Phase
A→B , Phase A→B , +Pulse Count,
-Pulse Count, Rise Edge Count, Fall Edge
Count, Area, and Cycle Area.
Waveform Math
＋, －, *, / ,FFT, FFTrms, Intg, Diff, Sqrt,
User Defined Function, digital filter (low
pass, high pass, band pass, band reject)
Decoding Type
(optional)
UART, I
2
C, SPI, CAN
Waveform storage
100 waveforms
Lissajous
figure
Bandwidth
Full bandwidth
Phase
difference
±3 degrees
Communication
port
USB Host, USB Device; Trig Out(Pass/Fail); LAN port
Printer
Compatibility
PictBridge
Counter
Support
Trigger
Performance Characteristics
Instruction
Trigger level range
Internal
±5 div from the screen center
Trigger level
Accuracy (typical)
Internal
±0.3 div
Trigger
displacement
According to Record length and time base
Trigger Holdoff
range
100 ns – 10 s
50% level setting
(typical)
Input signal frequency ≥ 50 Hz
Edge trigger
slope
Rising, Falling
Video Trigger
Modulation
Support standard NTSC, PAL and SECAM
broadcast systems
Line number range
1-525 (NTSC) and 1-625 (PAL/SECAM)
