Specifications
Power supply: AC 220 V to 240 V, 50 Hz
Power consumption: Approx. 40 W
Standby mode: (Power Save mode): Approx. 2 W
(Quick Start mode): Approx. 22 W
Recordable discs:
DVD-RAM: 2X SPEED (Ver. 2.0), 2-3X SPEED (Ver. 2.1)
2-5X SPEED (Ver. 2.2)
DVD-R (SL): 1X SPEED (Ver. 2.0), 1-4X SPEED (Ver. 2.0)
1-8X SPEED (Ver. 2.0), 1-16X SPEED (Ver. 2.1)
DVD-R (DL): 2-4X SPEED (Ver. 3.0), 2-8X SPEED (Ver. 3.0)
DVD-RW: 1X SPEED (Ver. 1.1), 1-2X SPEED (Ver. 1.1)
2-4X SPEED (Ver. 1.2), 2-6X SPEED (Ver. 1.2)
+R (SL): 2.4X SPEED (Ver. 1.0), 2.4-4X SPEED (Ver. 1.1)
2.4-8X SPEED (Ver. 1.2)
2.4-16X SPEED (Ver. 1.3)
+R (DL): 2.4X SPEED (Ver. 1.0), 2.4-8X SPEED (Ver. 1.1)
+RW: 2.4X SPEED (Ver. 1.1), 2.4-4X SPEED (Ver. 1.2)
Recording system:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer):
DVD-Video format
DVD-RW: DVD-Video format
+R
+R DL (Double Layer)
+RW
Recording time:
Max. 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour SP: Approx. 2 hours
LP: Approx. 4 hours EP: Approx. 6 hours or 8 hours
Maximum Approx. 441 hours with 250 GB HDD (EP 8 hours mode)
XP: Approx. 55 hours, SP: Approx. 110 hours
LP: Approx. 221 hours, EP:
Approx. 331 hours/441 hours
Playable discs:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format, MP3
1
, JPEG
1
, DivX
1
DVD-R DL (Dual Layer):
DVD-Video format, MP3
1
, JPEG
1
, DivX
1
DVD-RW: DVD Video Recording format, DVD-Video format
+R
+R DL (Double Layer)
+RW
DVD-Video, CD-Audio (CD-DA), Video CD, SVCD
2
CD-R/CD-RW:
CD-DA
1
, Video CD
1
, SVCD
1,2
, MP3
1
,
JPEG
1
, DivX
1
Internal HDD capacity: 250 GB
Optical pick-up:
System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER Specification:
Class 1 LASER Product
Wave Length: 780 nm (CDs)
662 nm (DVDs)
Laser Power: No hazardous radiation is emitted
with the safety protection
Television system:
Tuner System: DVB-T
Channel Coverage:
UK
UHF: 21 to 68 ch
RF converter output: Not provided
Video:
Video system:
PAL colour signal, 625 lines, 50 fields
NTSC colour signal, 525 lines, 60 fields
Recording system:
MPEG2 (Hybrid VBR)
Video In (PAL/NTSC):
AV1/AV2 (21 pin), AV3 (pin jack) 1 Vp-p 75 Ω, termination
S-Video In (PAL/NTSC):
AV2 (21 pin), AV3 (S terminal) 1 Vp-p 75 Ω, termination
RGB In (PAL):
AV2 (21 pin), 0.7 Vp-p (PAL) 75 Ω, termination
Video Out (PAL/NTSC):
AV1/AV2 (21 pin), Video Out (pin jack) 1 Vp-p 75 Ω, termination
S-Video Out (PAL/NTSC):
AV1 (21 pin), S-Video Out (S terminal) 1 Vp-p 75 Ω, termination
RGB Out (PAL/NTSC):
AV1 (21 pin) 0.7 Vp-p (PAL) 75 Ω, termination
Component video output (NTSC 480p/480i, PAL 576p/576i)
Y: 1.0 Vp-p 75 Ω, termination
P
B: 0.7 Vp-p 75 Ω, termination
PR: 0.7 Vp-p 75 Ω, termination
VHS:
Recording format:
VHS Video Cassette System Standard with FM audio
Heads: 4 Helical Scan Heads for Video
2 Helical Scan Heads for FM audio
1 Fixed Head for Normal audio
Tape speed/Recording time (with E-240 tape):
PAL: SP: 23.39 mm/s, 240 min
LP: 11.7 mm/s, 480 min
EP: 7.8 mm/s, 720 min
NTSC: SP: 33.35 mm/s, 168 min
EP: 11.12 mm/s, 505 min
Audio:
Recording system:
Dolby Digital (2 ch), Linear PCM (XP mode)
Audio In: AV1/AV2 (21 pin), AV3 (pin jack)
Input Level:
Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Input Impedance:
More than 10 kΩ
Audio Out: AV1/AV2 (21 pin), Audio Out (pin jack)
Output Level:
Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Output Impedance:
Less than 1 kΩ
Digital Audio Out:
Optical terminal (PCM, Dolby Digital, DTS, MPEG)
DV Input: IEEE 1394 Standard, 4 Pin: 1 pc
USB:
USB port: Type A: 1 pc
USB standard: USB 2.0 High Speed
Format: FAT16, FAT32
HDMI Output: 19 pin type A: 1 pc
HDMI
TM
(V.1.3 with Deep Colour)
This unit supports “HDAVI Control 3” function.
SD Card:
Slot: SD Memory Card Slot: 1 pc
Compatible media:
SD Memory Card
3
, SDHC Memory
Card, MultiMediaCard
Format:
FAT12, FAT16
4
(In case of SD Memory
Card, MultiMediaCard)
FAT32
4
(In case of SDHC Memory Card)
Still Picture (JPEG)
Image File Format:
JPEG conforming DCF (Design rule for
Camera File system)
Number of pixels: Between 34 × 34 and 6144 × 4096
Sub sampling: 4:2:2, 4:2:0
Thawing time: Approx.1.9 sec (6 M pixels, JPEG)
Video (SD-Video)
5
Codec: MPEG 2 (SD-Video Entertainment
Video Profile)
File Format: SD-Video format conforming
Quick Start for Recording & EPG Display (Power Save : OFF)
1 Sec. Quick Start for Rcecording & EPG Display
(when connecting to TV using 21-pin Scart, Component Video, Video
or S-Video terminals)
From the power on, recording on DVD-RAM and HDD starts in
about 1 second after the REC button is pressed. If the GUIDE
button is pressed while the unit is off, the Electronic Program
Guide (EPG) displays in less than 1 second. (Quick Start Mode)
Others
Regional Code: # 2
Operating temperature range:
5 °C to 40 °C
Operating humidity range: 10 % to 80 % RH (no condensation)
Dimensions (W×H×D): 430 mm × 84 mm × 341 mm
(excluding the projecting parts)
430 mm × 84 mm × 350 mm
(including the projecting parts)
Mass:
Approx. 6.3 kg
1 Finalising is necessary for compatible playback.
2 Conforming to IEC62107
This unit is not compatible with “Chaoji VCD” available on the
market including CVD, DVCD and SVCD that do not conform to
IEC62107.
3
Includes miniSD cards. (A miniSD adaptor needs to be inserted.)
Includes microSD cards. (A microSD adaptor needs to be inserted.)
4 Long file name is unsupported.
5 Video Recording conversion and transfer is possible from card or
Panasonic digital video camera with HDD etc, to HDD or DVD-
RAM disc. After Video Recording conversion and transfer to HDD
or DVD-RAM disc, the playback is possible.
Notes
Specifications are subject to change without notice.
Usable capacity will be less (SD Card).
•
•
