4
Thank you for placing your trust in the
Esprit
series of control panels. You've chosen a sophisticated,
user-friendly control panel designed to meet all of your technological, performance and security require-
ments. For your convenience and ease of use, almost all of the programming, and upload/download fea-
tures of
Esprit
panels are identical.
We hope that the important features of the
Esprit
line, which include Advanced Technology Zoning,
which allows 2 zones and a tamper on a single pair of wires, a 120-event, PC-uploadable event buffer,
and high-speed pre-programmed communicator formats, will simplify your task of supplying quality secu-
rity service to your customers.
ABOUT THIS MANUAL
This installation manual has been created to provide you with the information you will need to understand
panel operation, features and functions. The information in this manual is common to all Esprit panels
except where noted. It expands on the guidelines found in the
"Programming Guide
". The
"Programming Guide"
also contains information specific to the model you are installing. Even if you
are familiar with other security control panels, we recommend that you read this manual at least once to
familiarize yourself with panel features. Please refer to the index for a complete list of manual contents.
ABOUT PARADOX
We do our best to develop technologically-advanced control panels. If you have any comments or sug-
gestions, or if you require additional technical assistance, please contact your local distributor. Every
effort has been made to ensure that your distributor's staff has received complete training from Paradox
Security Systems so that you receive prompt and effective service.
CONTROL PANEL DESCRIPTIONS
All Panels have Upload and Download capability, telephone line monitor and fast formats. (Model 718
does not provide fast formats.)
Esprit 718 (UL/ULC listed)
Up to 5 hardwire zone control panel: Comprised of 3 onboard single zone inputs, up to 2 additional key-
pad zones (1 per keypad), 3 keypad-activated panic alarms. 1 PGM output, and 9 user codes. Enclosure
6.5”X9”X3” (16.5cmX22.8cmX7.6cm).
Esprit 728L (UL/ULC listed)
Up to 8 hardwire zone control panel: Comprised of 3 onboard doubled zone inputs (Advanced Technology
Zoning), up to 2 additional keypad zones (1 per keypad), 3 keypad-activated panic alarms, 1 PGM output,
120 event Buffer, and 9 user codes. Enclosure 6.5”X9”X3” (16.5cmX22.8cmX7.6cm).
Esprit 728 (UL/ULC listed - )
Up to 8 hardwire zone control panel: Comprised of 3 onboard doubled zone inputs (Advanced Technology
Zoning) up to 2 additional keypad zones (1 per keypad), 3 keypad-activated panic alarms, 1 PGM output,
120 event Buffer, partitioning and 17 User codes. Enclosure 8”X10”X3” (20.3cmX25.4cmX7.6cm)
Esprit 738 (UL/ULC listed - )
Up to 14 hardwire zone control panel: Comprised of 6 onboard doubled zone inputs (Advanced Technology
Zoning), up to 2 additional keypad zones (1 per keypad), 3 keypad-activated panic alarms, 2 PGM outputs,
120 event Buffer, alarm relay, partitioning and 17 User codes. Enclosure 11”X11”X3” (28cmX28cmX7.6cm)
Esprit 748 (UL/ULC listed - )
24 hardwire zone control panel: Comprised of 12 onboard doubled zone inputs (Advanced Technology
Zoning) and 3 keypad-activated panic alarms. Keypad zones are displayed in parallel to zones 13 and 19.
2 PGM outputs, 120 event Buffer, alarm relay, partitioning and 17 User codes. Enclosure 11”X11"X3”
(28cmX28cmX7.6cm)
Esprit 748ES (UL listed - )
24 hardwire zone control panel: 24 single zone inputs and 3 keypad-activated panic alarms. Keypad
zones displayed in parallel to zones 13 and 19. Aux power: 1.2A, (Fuseless electronic shut down at 3A,
automatic restore). 5 pairs of AUX terminals, 2 PGM outputs, 120 event Buffer, 17 User codes and alarm
relay. Enclosure 14”x12.5”x4” (35.6cmX31.8cmX10.2cm)
