Digital Communicator:
Compatible with most telecommunication standards world wide.
Reporting formats:
Pulse: Ademco slow (10BPS), Silent Knight fast, Sescoa (20 BPS) Radionics, Radionics
with parity (40 BPS), 1400Hz - 1800Hz (20 BPS)
DTMF: Contact ID, Ademco Express, “No handshake” DTMF format.(Pager)
Optional SIA format (Standard on 708 )
True Dial tone detection and telephone line monitoring.
Full Up/down loadable with PC.
Regular, Split and Double reporting modes.
Event Buffer: ( 728L , 728 , 738 , 748 , 748ES )
120 event buffer with time and date.
Operating modes:
17 User codes (2 Master codes) 4 or 6 digit codes. ( 728 , 738 748 , 748ES )
9 User codes (2 Master codes) 4 or 6 digit codes. ( 718, 728L )
Partitioning to System "A", System "B" and a Common area. ( 728 , 738,748 , 748ES )
Stay (at Home), regular, and auto bypass (Away) arming.
Fast “One key Full Arm”, “One key Stay Arm” and “One key Exit”.
Key Switch Arm/Disarm ("stay" or "regular" mode.)
PS1 bedside remote, 3 keypad-activated panic alarms.
Real Time Clock for "list of events", auto arming and test reports.
Auto arm on time or no zone activity delay time.
Inputs and Outputs:
Zones: N.C., EOL or "Advanced Technology Zoning" and wire/tamper recognition using 1 resistor per zone.
Battery Charger: 360mA with active Battery test.
Aux power: 400 mA, (UL, ULC installations) Fuseless electronic shut down at 1A, Automatic restore
Bell Out: 1A, (Fuseless electronic shut-down at 3A, Automatic restore)
AC input: 16.5 Vac, 40VA (75VA for 748ES @ 1.2 amps)
PGM outputs: More than 1000 options to follow
2 operation modes: Timed (1 sec. to 2 hrs.) or following a predetermined condi tion.
N.C. or N.O to ground, 30 mA Max. Can also be remote controlled by PC.
Serial Data Output (1200,1, N) for use with Accessory Modules
Accessory Modules:
SRI 18: 18 PGM outputs, 708: Secondary Digital Dialer (UL listed)
708DV: DVACS communicator (Canada only), Esprint: Parallel printer interface (not UL listed).
Keypads:
616, 626, 629 and 633 (LED) keypads. 639 and 640 (LCD) keypads, PS1 bedside remote. (For UL
systems use only 616, 626, 640 or PS1.)
Current consumption:
(measured with battery connected, without AC and 1KW resistor on bell and 1KW resistor on zones)
718 control panel : 29mA
DC
616/626 LED keypads: 15mA
DC
Typical
728 control panel : 29mA
DC
30mA
DC
Maximum
728L control panel : 29mA
DC
629 access control keypad: 30mA
DC
Typical
738 control panel : 25mA
DC
55mA
DC
Maximum
748 control panel : 37mA
DC
633 LED keypad: 15mA
DC
Typical
748ES control panel : 60mA
DC
35mA
DC
Maximum
PS1 bedside remote: 15mA
DC
Typical 639/640 LCD keypads: 20mA
DC
Typical
20mA
DC
Maximum 45mA
DC
Maximum
SR!-18: 50mA
DC
Typical
7
IM8
