- Remove the special tool and extract the counter-
shaft with the control gear.
Replacing the countershaft bearings
- Check that the bearings are free from irregular
noise or clearance. If it does, replace it.
Flywheel-side half-crankcase
- Remove the inside Seeger ring.
- Upturn the half-crankcase.
- Remove the bearing from the flywheel side half-
crankcase using the special tool and a mallet.
Specific tooling
020376Y Adapter handle
020358Y 37 x 40 mm adaptor
020439Y 17 mm guide
- Remove the bearing from the transmission side
half-crankcase using the special tool.
Specific tooling
001467Y008 Calliper to extract 17-mm diame-
ter bearings
001467Y007 Bell for OD 54-mm bearings
MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA (2015) Engine
ENG - 223
