Parking brake
- Remove the rear wheel.
- Loosen the transmission set screw and release
the cable from the calliper.
- Undo the two fixing screws of the mechanical
calliper and remove it.
- When refitting, secure to the prescribed torque.
Locking torques (N*m)
Parking brake - Screw tightening calliper to
support (Apply medium LOCTITE threadlock
of type 243) 24 - 27
- For an easier operation, previously remove the
calliper support plate by acting on the safety locks
and unscrewing the two fixing bolts as indicated in
the picture.
MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA (2015) Braking
system
BRAK SYS - 389
