7. PMP CONNECTION
Remove the leg shield to reach it.
8. BRAKE CALLIPER SENSOR
Remove the leg shield to reach it.
The sensor connector is fixed to the frame under
the expansion tank.
9. PRESSURE SENSOR
Remove the leg shield to reach it.
Electrical system MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA
(2015)
ELE SYS - 66
