Dimensions and mass
WEIGHTS AND DIMENSIONS
Specification
Desc./Quantity
Length 2205 mm (86.8 in)
Width 775 mm (30.5 in)
Maximum height 1460 mm (57.5 in)
Wheelbase 1540 mm (60.6 in)
Track 465 mm (18.3 in)
Kerb weight 266 kg (586 lb)
Maximum weight limit 460 kg (1014 lb)
Engine
ENGINE TECHNICAL DATA
Specification
Desc./Quantity
Type Single-cylinder, 4-stroke
Engine capacity 493 cm³
Bore x Stroke 94 x 71 mm
Compression ratio 10.5 ± 0.5 : 1
Engine idle speed 1,600 ± 100 rpm
Timing system Four valves, single overhead camshaft, chain-driven.
Valve clearance Inlet: 0.15 mm
Outlet: 0.15 mm
MAX. power 29.5 kW at 7,250 rpm
MAX. torque 45.5 Nm at 5,250 rpm
Transmission CVT expandable pulley variator with torque server, V-belt, self-
ventilating dry automatic centrifugal clutch and transmission
housing with forced-circulation air cooling.
Final reduction with gear reduction unit in oil bath.
Lubrication Engine lubrication with lobe pump (inside crankcase), chain-
driven, with double filter: mesh and paper.
MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA (2015)
Characteristics
CHAR - 9
