47. ABS CONTROL UNIT (IF APPLICABLE)
Remove the helmet compartment to reach it.
Ground points
On the vehicle there is a chassis ground point
"A", remove the footrest to access it.
There is another ground point "B" on the starter
motor, remove the helmet compartment to reach
it.
On the left side of the vehicle is an engine-chassis
ground cable «C» fixed, remove the footrest and
the side fairing to reach it.
MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA (2015) Electrical
system
ELE SYS - 75
