020330Y Stroboscopic light for timing checking
Proceed as follows:
- Remove the transmission compartment cover as
described in the "automatic transmission" chapter.
- Remove the TDC reference inspection cap be-
tween flywheel and crankcase cover. See the "fly-
wheel cover" chapter
- By the driving pulley, turn the engine to find the
alignment of the references to identify the TDC.
- Repeat for the reference between driving pulley
and engine crankcase.
Injection MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA (2015)
INJEC - 290
