N.B.
THE UNITS OF MEASUREMENT CONTAINED IN THIS CHAPTER ARE EXPRESSED IN TERMS
OF THE DECIMAL METRIC SYSTEM. TO REFER TO THE UNIT OF MEASUREMENT EXPRESSED
IN TERMS OF THE ANGLO-SAXON SYSTEM, SEE THE «CHARACTERISTICS» CHAPTER.
SERVICE ICON RESET
When switching to «ON», immediately after the ig-
nition check, if there are less than 300 km (187.5
miles) to the next scheduled service, the corre-
sponding icon flashes for 5 seconds. Once the
service mileage has been reached, the icon re-
mains steadily on until it is reset. The icon reset is
carried out by pressing the button «SET» for more
than 10 seconds when switching to «ON»: the icon
with the key, after the ignition check, must flash
with a frequency of 1 Hz and then turn off after 10
seconds to indicate the performed reset. If the but-
ton is released before the 10 seconds, the icon is
not reset.
ADJUSTMENT PROCEDURE OF THE RING NUTS OF THE SIDE HEADSTOCKS
- Remove the windshield.
- Remove the central cover fixed to the joints on
the legshield.
- Remove the two indicated daylight running light
fixing screws.
- Remove the daylight running light by disconnect-
ing the connector.
Maintenance MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA
(2015)
MAIN - 32
