Removal
Proceed as follows:
- Remove the rear brake calliper.
- Remove the two pins holding the brake pads.
- Remove the pads, paying attention to the pad re-
taining spring.
- Check the thickness of the pads.
If the thickness is less than the minimum value,
replace the pads with new pads.
Characteristic
Minimum value
1.5 mm
Refitting
- To fit the rear brake pads, follow the removal steps but in reverse order; be careful to tighten the screws
to the prescribed torque.
Locking torques (N*m)
Screws tightening the pad fixing pin 20 ÷ 25 Nm
Fill
Rear - combined
For the procedure in question see «Various documents» section.
Front
For the procedure in question see «Various documents» section.
MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA (2015) Braking
system
BRAK SYS - 387
