Hub oil
Check
- Rest the vehicle on its centre stand on level
ground.
- Unscrew the dipstick «A», dry it with a clean rag
and then reinsert it, screwing it tightly into
place.
- Extract the dipstick checking that the oil level is
between the MAX and MIN index marks; if the lev-
el is below the MIN mark, it needs to be filled up
with the right amount of hub oil.
-Screw up the oil dipstick again and make sure it
is locked properly into place.
Replacement
- Remove the oil filler plug «A».
- Unscrew the oil drainage cap «B» and drain out
all the oil.
- Screw in the drainage cap again and fill the hub
with the prescribed oil.
Recommended products
AGIP GEAR SAE 80W-90 Lubricant for gear-
boxes and transmissions.
API GL-4
Characteristic
Rear hub oil
Capacity approximately 250 cc
MP3 500 i.e. SPORT Business_LT_ ABS-ASR_EU_USA (2015)
Maintenance
MAIN - 41
