Refitting the wheel axle bearing
- Support the hub cover on a wooden surface.
- Heat the crankcase cover with the specific heat
gun.
- Fit the wheel shaft bearing with a modular punch
as shown in the figure.
- Fit the seeger ring.
- Fit the oil guard with seal lip towards the inside
of the hub and place it flush with the internal sur-
face by means of the appropriate tool used from
the 52 mm side.
The 52 mm side of the adapter must be turned to-
wards the bearing.
Specific tooling
020376Y Adaptor handle
020360Y Adaptor 52 x 55 mm
020483Y 30 mm guide
X7 250ie Engine
ENG - 21

PIAGGIO X7 250ie Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	244 cc
Fuel System	Electronic fuel injection
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
Seat Height	790 mm
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Max Power	16.2 kW (22 hp) at 8, 250 rpm
