PIAGGIO X7 250ie User Manual

- Undo the screw indicated on both sides of the
vehicle.
See also
Footrest
Front wheel housing
- Remove the front shield.
- Remove the fork
- Undo the screw indicated.
- Undo the screw indicated from both sides of the
vehicle.
See also
Legshield
Chassis X7 250ie
CHAS - 8

PIAGGIO X7 250ie Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	244 cc
Fuel System	Electronic fuel injection
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
Seat Height	790 mm
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Max Power	16.2 kW (22 hp) at 8, 250 rpm
