PIAGGIO X7 250ie User Manual

a pair of long flat needle-nose pliers, choke the fuel pipe making the pressure stabilise at approx. 2.5
BAR. Check that, in fifteen seconds, the pump has a flow rate of around 110 cm³.
Specific tooling
020480Y Petrol pressure check set
Fuel filter check
Disconnect the terminals from the electric pump
Remove the screw shown in the photograph
Remove the clip fixing the piping to the filter shown
in the photograph
Injection X7 250ie
INJEC - 20

PIAGGIO X7 250ie Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	244 cc
Fuel System	Electronic fuel injection
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
Seat Height	790 mm
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Max Power	16.2 kW (22 hp) at 8, 250 rpm
