Rear handlebar cover
Front handlebar cover
- Remove the windshield and the front central cov-
er.
- Undo the screw indicated from both sides of the
vehicle.
- Undo the screw indicated and remove the front
handlebar cover.
See also
Front central cover
Flyscreen
Headlight assy.
- Remove the front central cover.
- Undo the three screws indicated.
Chassis X7 250ie
CHAS - 4

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PIAGGIO X7 250ie and is the answer not in the manual?

PIAGGIO X7 250ie Specifications

General IconGeneral
Engine TypeSingle cylinder, 4-stroke
Displacement244 cc
Fuel SystemElectronic fuel injection
Rear SuspensionDual hydraulic shock absorbers
Rear Brake240 mm disc
Seat Height790 mm
Cooling SystemLiquid cooled
TransmissionCVT
Front SuspensionTelescopic fork
Front BrakeDisc
Max Power16.2 kW (22 hp) at 8, 250 rpm
