PIAGGIO X7 250ie User Manual

Tachometer
With wiring disconnected from the control unit and
connected to the system, check that the sensor
resistance between pins 13 - 15 is between 100
and 150 Ohm at an engine temperature of approx-
imately 20°
Disconnect the fuel pipe connector. Start up the
engine and wait for it to stop. With the wiring con-
nected to the control unit and system try to start up
the engine and check that the voltage between
pins 13 and 15 is around 2.8 V
Injection X7 250ie
INJEC - 28

PIAGGIO X7 250ie Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	244 cc
Fuel System	Electronic fuel injection
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
Seat Height	790 mm
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Max Power	16.2 kW (22 hp) at 8, 250 rpm
