PIAGGIO X7 250ie User Manual

This section describes the operations to be carried out on the engine and the tools to be used.
Automatic transmission
Transmission cover
- To remove the transmission cover it is necessary
to remove the plastic cover first, by inserting a
screwdriver in the slotted holes. Using the clutch
bell lock wrench shown in the figure, remove the
driven pulley shaft locking nut and washer.
Specific tooling
020423Y driven pulley lock wrench
- Remove the cap/dipstick from the engine oil filling
hole.
- Remove the ten screws.
Engine X7 250ie
ENG - 2

PIAGGIO X7 250ie Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	244 cc
Fuel System	Electronic fuel injection
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
Seat Height	790 mm
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Max Power	16.2 kW (22 hp) at 8, 250 rpm
