PIAGGIO X7 250ie User Manual

Seat
- Lift the saddle and undo the three screws indica-
ted.
Driving mirrors
- Unscrew the lock-nut and slide off the rear-view
mirror stem.
Rear handlebar cover
- Remove the front handlebar cover.
- Undo the two screws indicated.
Chassis X7 250ie
CHAS - 2

PIAGGIO X7 250ie Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	244 cc
Fuel System	Electronic fuel injection
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
Seat Height	790 mm
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Max Power	16.2 kW (22 hp) at 8, 250 rpm
