Electrode distance 0.8 mm
N.B.
GREASE THE END STOP RING TO PREVENT
IT COMING OUT AND FALLING INTO THE EN-
GINE.
Locking torques (N*m)
Timing chain tensioner support screw 11 ÷ 13
Spark plug 12 ÷ 14 Starter ground screw 7 ÷
8.5 Timing chain tensioner slider screw 10 ÷
14 Starter ground support screw 11 ÷ 15 Timing
chain tensioner central screw 5 - 6 Camshaft
retention plate screw 4 ÷ 6
Engine X7 250ie
ENG - 48
