Pioneer VSX-1020-K Service Manual

104
VSX-1020-K
1
2 3 4
A
B
C
D
E
F
1
2 3 4
11.2 COMPONENT ASSY
B
B
COMPONENT ASSY
SIDE A SIDE A
C
CN8501
CN8007
O
CP6
CN8017
O
CN5002
CN8012
N
CN1254
CN8001
N
CN1252
CN8003
N
CN1250
CN8005
E
J3652
CN8016
IC8061 IC8041 IC8042
IC8051
IC8101
IC8451
IC8084 IC8083 IC8082
Q8303
Q8082
IC8311 IC8351
IC8361
IC8441
Q8201 Q8201
Q8211 Q8212
Q8221 Q8222
Q8241 Q8242

Pioneer VSX-1020-K Specifications

Power

power requirements	AC 120 V/60 Hz
power consumption	245 Watts
standby power consumption	Less than 0.5 Watts

Weight and Dimensions

width	16.55 inches
height	6.23 inches
depth	14.93 inches
weight	22.4 lbs
