Pioneer VSX-1020-K Service Manual

126
VSX-1020-K
1
2 3 4
A
B
C
D
E
F
1
2 3 4
11.9 BRIDGE1, GUIDE3 GIUIDE-L and GUIDE-R ASSYS
P Q R S
P
BRIDGE1
ASSY
Q
GUIDE3 ASSY
R
GUIDE-L ASSY
S
GUIDE-R ASSY
SIDE A SIDE A
A
CN2201
CN7602
N
CN1401
CN7601

Pioneer VSX-1020-K Specifications

Power

power requirements	AC 120 V/60 Hz
power consumption	245 Watts
standby power consumption	Less than 0.5 Watts

Weight and Dimensions

width	16.55 inches
height	6.23 inches
depth	14.93 inches
weight	22.4 lbs
