Pioneer VSX-1020-K Service Manual

128
VSX-1020-K
1
2 3 4
A
B
C
D
E
F
1
2 3 4
12. PCB PARTS LIST
-
Meaning of the figures and others in the parentheses in the parts list.
Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding PC board.
IC 301 (A, 91, 111) IC NJM2068V
5 6 2 1
1 R 0
R 5 0
5 6 1
4 7 3
NOTES:
-
Parts marked by “NSP” are generally unavailable because they are not in our Master Spare Parts List.
-
The > mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
-
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47 k ohm (tolerance is shown by J = 5%,
and K = 10%).
560 Ω → 56 × 10
1
→ 561
...................................................................
RD1/4PU J
47 kΩ → 47 × 10
3
→ 473
...................................................................
RD1/4PU J
0.5 Ω → R50
.................................................................................................
RN2H K
1 Ω → 1R0
.................................................................................................
RS1P K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62 kΩ → 562 × 10
1
→ 5621
.................................................................
RN1/4PC F
JA*** JACK***, JK***
RY*** RLY***
T*** PT***
X*** XTAL***, RES*** (CERAMIC)
FU*** F***
V*** FLT***
S*** SW***, VEC*** (ENCODER)
L*** FB***
CN*** CP***, PN***
Q*** Q***FL, Q***FR, Q***C, Q***SL, Q***SR
D*** ZD***
-
SCHEMATIC DIAGRAM and PCB CONNECTION DIAGRAM
-
PCB PARTS LIST
Mark No. Description Part No.
LIST OF ASSEMBLIES
NSP 1..MAIN ASSY 7025HK0918010-IL
2..MAIN ASSY 7028069211010-IL
2..BRIDGE1 ASSY 7028069213010-IL
2..GUIDE-L ASSY 7028069214010-IL
2..GUIDE-R ASSY 7028069215010-IL
2..GUIDE3 ASSY 7028069218010-IL
NSP1..FRONT ASSY (VSX-1020-K) 7025HK0918011-IL
NSP1..FRONT ASSY (VSX-1025-K) 7025HK0918051-IL
2..DISPLAY ASSY (VSX-1020-K) 7028069221010-IL
2..DISPLAY ASSY (VSX-1025-K) 70280692210C0-IL
2..DISPLAY ASSY 7028069221010-IL
2..POWER SW ASSY 7028069222010-IL
2..USB MTG ASSY 7028069223010-IL
2..HDMI MTG ASSY 7028069224010-IL
2..HEADPHONE ASSY 7028069225010-IL
NSP1..AMP ASSY 7025HK0918012-IL
2..AMP ASSY 7028069531010-IL
NSP1..INPUT ASSY 7025HK0918013-IL
2..AUDIO ASSY 7028069241010-IL
2..COMPONENT ASSY 7028069242010-IL
2..COMPOSITE ASSY 7028069243010-IL
2..BRIDGE2 ASSY 7028069244010-IL
2..F-VIDEO ASSY 7028069245010-IL
2..MIC ASSY 7028069246010-IL
NSP
1..F-HDMI ASSY 7025HK0918014-IL
2..F-HDMI ASSY 7028069251010-IL
NSP 1..D-MAIN ASSY 7025HK0918015-IL
2..D-MAIN ASSY 7028069261010-IL
Mark No. Description Part No.
A
AUDIO ASSY
SEMICONDUCTORS
IC 2501 BD3473KS2
IC 2502 J040406600010-IL
IC 2701,2702,2741,2761 J121458000020-IL
IC 2781,2801,2821 J121458000020-IL
Q 2001,2002,2312-2320 INC2001AC1
Q 2401,2681 J5023209Y0010-IL
Q 2402 J5001281Y0010-IL
Q 2701 J520103S00210-IL
Q 2702 J522101411210-IL
D 2401,2402 UDZS7R5(B)
D 2501,2502,2603-2616 K005041480030-IL
D 2681 UDZS10(B)
MISCELLANEOUS
JA 2101-2103 TER,RCA 6PIN G603603A0500Y-IL
JA 2107 TER,RCA 1PIN G600107A0000Y-IL
CN 2102 CN,WAFER L109012522310-IL
CN 2106 CN,WAFER L109012521710-IL
CN 2201 CN,WAFER L109012521310-IL
B
COMPONENT ASSY
SEMICONDUCTORS
IC 8041,8051 CD74HC4053PW
IC 8061 NJM2581M
IC 8082,8083 KIA7805API
IC 8084 J126790500070-IL
IC 8101 BU4094BCFV
IC 8351,8361,8441 SN74AHCT08PW
Q 8082 J522101411210-IL
