Pioneer VSX-1020-K Service Manual

114
VSX-1020-K
1
2 3 4
A
B
C
D
E
F
1
2 3 4
11.6 DISPLAY, HEADPHONE and POWER SW ASSYS
K M
K
DISPLAY ASSY (1/2)
M
POWER SW ASSY
K
DISPLAY ASSY (2/2)
SIDE A
POWER
TRANSFORMER
CN3004
O
CN55
CN3003 CN3002A
CN3002B
CN3001
CN3501

Pioneer VSX-1020-K Specifications

Power

power requirements	AC 120 V/60 Hz
power consumption	245 Watts
standby power consumption	Less than 0.5 Watts

Weight and Dimensions

width	16.55 inches
height	6.23 inches
depth	14.93 inches
weight	22.4 lbs
