Pioneer VSX-1020-K Service Manual

22
VSX-1020-K
1
2 3 4
A
B
C
D
E
F
1
2 3 4
4.6 GND BLOCK DIAGRAM
N
D-MAIN ASSY
D
MIC ASSY
E
F-VIDEO
ASSY
B
COMPONENT ASSY
C
COMPOSITE ASSY
A
AUDIO ASSY
G
F-H

Pioneer VSX-1020-K Specifications

Power

power requirements	AC 120 V/60 Hz
power consumption	245 Watts
standby power consumption	Less than 0.5 Watts

Weight and Dimensions

width	16.55 inches
height	6.23 inches
depth	14.93 inches
weight	22.4 lbs
