Pulsar Model 22 User Manual
Page 42
Section 5 Reviewing & Downloading Measurements
Once measurements have been downloaded from the dosemeter into the Reader unit,
they are stored in the memory of the Reader automatically. The measurements can be
reviewed on the display of the Reader unit or they can be downloaded from the Reader
to the Pulsar AnalyzerPlus software.
Reviewing stored measurements
Press the Cancel button to exit any menus and return to
the Measurement Display Mode. If there are no
measurements stored in the Reader unit, the following
information will be displayed:
Where measurements are stored, the Reader will show the last measurement to be
downloaded as follows:
This display shows that there are 10 measurements stored
in the memory of the Reader and that the measurement
shown is number 1 of 10.
The arrow keys allow the measurement information to be
viewed and the different measurements to be accessed as
follows:
The information stored for each measurement will be determined by the configuration
of the dosemeter.
Please note that the information provided by the 3dB configuration will include
L
Aeq
and L
EX,8
data only if the Threshold Level is None and if the Time
Weighting is None. If either of these parameters are set to other values, the
measurement data will be displayed as L
AVG
and TWA.
L
Aeq
and L
EX,8
data cannot be calculated where a Threshold or a Time Weighting are
used. Ensure that the dosemeter is correctly configured before making measurements.
Measurement data cannot be recalculated after the measurement has been made.
An example of the measurement data parameters provided are shown on the next
page.
Please note that the Pulsar AnalyzerPlus software allows the user to select which
additional measurement functions are displayed on the Reader display. When these
additional parameters are downloaded, they are automatically stored in the Reader unit
but are not displayed on the screen.
000 of 000
17:05:28 20/06/02
No Measurements
001 of 010
12:42:53 28/02/05
Serial No. CA015
Meas. Time 16:55
Meas Date 06/02/05
Run Time 07:45:12
