10
TD-001578-01-C
Input Channel − Presets
The MP-M includes presets for speech and musical
instruments. The musical instrument presets are intended
for applications in which the Mixer section is used for
reinforcement of live entertainment.
An Input Channel Preset consists of settings for the
channel EQ, dynamics and gate that can be saved and
recalled. The channel name and level settings are also
stored with the preset but may be omitted from a preset
recall by setting the Recall Omits switches to omit them.
Factory Presets
1.
Presets
button – Displays the Presets screen.
2.
Preset Info
button – Touch to displays a pop-up
message with details about the current Preset. Touch
OK on the pop-up to close.
3.
Current Preset
field – Displays the name of the
currently active preset.
4.
Factory / User switch
– For this topic, set the
switch to Factory. Selects between the internal factory
presets or user presets. Refer to the User Presets topic
for details.
5.
Recall Omits
– Allows selected parameters to be
unaffected by a preset recall. The parameters that can be selected are:
Levels
,
Name
,
12V
phantom power. The parameter is selected when
the switch is “on”.
6.
Recall
button – Touch to recall the preset selected in the Selection windows.
7.
Selection windows
– These windows (
Input
,
Type
, and
Preset Name
) are used to select a preset for recall.
Inputs Touch an Input Bank
Touch a Channel
Presets Button
Mic/Line
(RCA / More)
12 V
3
4
6
5
2
7
To Next Page
