QSC MP-M User Manual

18
TD-001578-01-C
Input Channel − USB Player
Use the USB Player for MP3 playback from a USB storage
device attached to one of the MP-M USB ports.
• The USB storage device must be formatted FAT32.
• The audio files must be in the root directory.
• Files are displayed in alpha-numeric order.
• MP3 files must have a sample rate of 44.1k.
• USB Playback must be enabled from Menu > Settings
in order for this feature to be available for the MP
Manage app.
1. Audio Player button – Selects the Audio
Playerscreen.
2. MP3 Songs – Displays a list of MP3 titles on the
inserted USB drive.
3. Digital Trim – Provides input gain control. (-12 dB to
0.00 dB)
4. Playback Mode –
•
Normal button – plays the files in listed order
(alpha-numeric)
• Shuffle button – plays the files in random order.
• Single button – plays the selected file one time. Does not repeat.
5. MP3 – Displays title of currently selected MP3 file.
6. Top-of-List – Touch to move to the beginning of the filelist.
7. Previous file – Touch to move to the previous file in the file list.
8. Play – Touch to begin playback of the currently selected MP3 file.
9. Next file – Touch to move to the next file in the file list.
10. Stop Play – Touch to stop playback of the currently selected MP3 file.
11. Playback Time – Indicates elapsed time since beginningplayback.
12. Progress Line indicates the approximate playback position in the file.
13. Position Progress – Touch, hold, and drag to desired position on the Progress Line.
14. 00:00:00 – Represents the start of the file.
15. HH:MM:SS – Indicates the length of the file.
Inputs
Touch Input Bank
More
Touch Audio Player
Button
More
3 4
1
10
9
6
8
11
5
12
2
7
15
13
14
