QSC MP-M User Manual

22
TD-001578-01-C
Output Zones – Home Screen
The Outputs Home screen displays the processing blocks for
the output channels. Touch any block to see the associated
controls and displays for the Output Zone processing block.
1. Zones / Music on Hold (MP-M80 shown) – Zones
displays the Zones (output channels) and processing
block for the corresponding Zones. Music on Hold
displays the Music on Hold output channel and its
processing blocks.
2. Titles for the processing block columns.
3. Linked stereo processing block.
4. Mono processing block.
5. Light-colored blocks (highlighted) indicate that the block
is engaged.
6. Dark-colored blocks indicate that the block is
notengaged.
3
4
1
6
5
2
