QLS-4100 Xe 3-11
Calibrating Reflective Media
1 Lift each of the printheads for this calibration routine in order to
conserve ribbon. Disengage the drive roller by turning the Drive Roll Lift
Lever clockwise.
2 Position the reflective mark so that the red light from the reflective
sensor passes through the mark. The light will typically pass through
most media allowing you to view the mark from above. On more opaque
media, you may have to view the mark from the bottom.
3 Engage the drive roller by turning the Drive Roll Lift Lever
counterclockwise.
4 Press the PRINT/PAUSE key until the printer is in a paused state.
5 Press the NEXT or PREVIOUS key until the Cal & Setup menu is
displayed, then press the SELECT key.
6 Press the NEXT or PREVIOUS key until the Calibrate menu is displayed.
7 Press the + or - key until Reflective is displayed.
8 Press the SELECT key. The display will show the following prompt:
9 Press the SELECT key again. The display will show the following
prompt:
Place Media @ Sensor
Then Press Select
Place Mark @ Sensor
Then Press Select
Calibrate
Reflective
Pause: Cal & Setup
Press SELECT
To Next Page
