CHAPTER 10
66 Raven RS1™ and RS Lite™ Calibration and Operation Manual
522825 .19 TCU disconnected.
1. Check cabling and connections.
2. Check machine TECU version and OMNiDRIVE
unlock.
3. Create a new RS1 profile.
522826 .16 Invalid pitch.
A pitch greater than 15° has been detected for an
extended period of time. Confirm that the RS1 is
mounted securely to a flat surface. Confirm that any
sunroofs are closed.
If the issue persists, re-calibrate the terrain
compensation. Review the Terrain Compensation Setup
section on page 45 for additional assistance.
523766 .31
Steering control partner
serial number mismatch.
Select the correct steering profile or connect to the
correct machine and steering control unit.
523827 .0
Reverse steer not
supported.
Reverse steering is not supported on this machine. If the
machine is moving forward when this DTC activates,
select the direction toggle icon on the field computer or
the RS1 UT.
523830 .31 Steering not unlocked.
Enter a steering unlock code. An unlock code is not
necessary if using a SmarTrax MD unit.
523832 .0 GPS mode not unlocked.
Contact a local Raven dealer for a GNSS unlock or select
a different GNSS correction type.
523839 .31
Selected tuneset not
released.
1. Update the RS1 software for the latest list of released
tunesets.
2. Recalibrate RS1 using a generic tuneset.
523842 .31 Liability acceptance. Accept the RS1 liability.
523843 .0
Lost internal
communication.
1. Cycle power to the RS1.
2. Ensure proper CAN termination.
3. Check cabling and connections.
Code ID Description Recommended Actions
